Flexx Handlebar E-MTB
The Flexx Handlebar E-MTB
Now built on a 35mm clamp area, the all alloy Flexx E-Mtb isolates your upper body from abuse and vibration, allowing you to ride longer and charge harder. Flexx Handlebars are tunable to your preferences, you control how soft or stiff the bar is.
Flexx Handlebars are precise in the steering path yet forgiving in the load path, yielding uncompromised control and abuse reduction. Flexx Handlebars provide the feedback of a traditional bar while taking the edge off of the abuse.
Made in the USA and built from 7075 aluminum, the pivot point is the back bone of our design and philosophy, providing rigidity to channel the abuse through the elastomers. Titanium pivot pins and hardware mate the components together and retain the elastomers.
All Flexx Handlebars will ship with natural titanium hardware. To purchase Black Ti, Oil Slick Ti, or Burnt Blue Ti hardware, CLICK HERE.
Rise: 25mm
Clamp Diameter: 35mm
Weight: 650g
Width: 800mm
Upsweep: 5°
Back sweep: 8° & 12°
Center Tube Width: 63mm
Materials: 7075 Aluminum, Ti-6Al-4V
Effective suspension travel: 5°, length of bar dictates overall travel.
-The pin end caps do not need to be removed to change elastomers, use blue loctite on the nut and bolt when re-assembling
Patent#6,860,500
Elastomers included:
Soft (blue), medium (yellow), hard (red), and extra hard (black). Compression and rebound. For more elastomer info, click HERE.
Recommended Elastomer Combinations:
BLUE: XC/Gravel, youth, lightweight riders, 140lbs or less
YELLOW: XC/Trail/mild Enduro, 140-165lbs
RED: Enduro/DH, 150lbs-220lbs, most popular set up
BLACK: DH 190lbs +
- A properly tuned Flexx Handlebar should feel natural while riding, absorbing small bumps, chatter and other trail terrain that tends to make your hands and upper body more fatigued. Any diving sensation, bottoming out or "that doesn't feel right" is an indication your set up is too soft.
1. Flexx Handlebar
2. Complete elastomer kit
